INTEL PROCESSOR ULTRA 5 245K LGA1851 3Y

INTEL PROCESSOR ULTRA 5 245K LGA1851 3Y

Spesifikasi Utama:

- Product Collection: Intel® Core™ Ultra Series 2

- Codename: Arrow Lake

- Segment: Desktop Enthusiast

- Processor Number: 245K

- Total Cores: 14 (6 Performance + 8 Efficient)

- Total Threads: 14

- Max Turbo Frequency: 5.2 GHz

- P-core Base/Boost: 4.2 GHz / 5.2 GHz

- E-core Base/Boost: 3.6 GHz / 4.6 GHz

- Cache: 24MB Intel® Smart Cache + 26MB L2 Cache

- Base Power: 125W

- Max Turbo Power: 159W

- Lithography: TSMC N3B

- Socket: FCLGA1851

- Launch Date: Q4 2024

Memori:

- Max Capacity: 256GB

- Memory Type: DDR5 up to 6400 MT/s

- Channels: Dual-Channel

- ECC Support: Yes

Grafis Terintegrasi:

- Intel® Graphics dengan 4 Xe-cores

- Base Frequency: 300 MHz

- Max Dynamic Frequency: 1.9 GHz

- GPU Peak TOPS (Int8): 8

- Output: eDP 1.4b, DP 2.1 UHBR20, HDMI 2.1 FRL

- Max Resolution:

- HDMI: 4096x2304@60Hz (TMDS), 7680x4320@60Hz (FRL)

- DP: 7680x4320@60Hz

- eDP: 3840x2400@120Hz

- DirectX 12, OpenGL 4.5, OpenCL 3

- Encode/Decode: H.264, H.265, AV1

- Intel® Quick Sync Video: Yes

- Displays Supported: 4

AI & NPU:

- Intel® AI Boost NPU, Peak 13 TOPS (Int8)

- CPU AI Performance: 30 TOPS (Int8)

- GPU AI Performance: 8 TOPS (Int8)

- Supported Frameworks: OpenVINO™, WindowsML, DirectML, ONNX RT, WebNN, WebGPU

- Windows Studio Effects: Yes

Ekspansi & Konektivitas:

- PCIe Revision: 5.0 & 4.0

- PCIe Lanes: 24 (config up to 1x16+2x4, 2x8+2x4, 1x8+4x4)

- DMI Revision: 4, 8 lanes

- Thunderbolt™ 4: Yes

- Scalability: 1S Only

Teknologi & Keamanan:

- Intel® Thread Director, Speed Shift, Turbo Boost 2.0

- Intel® Gaussian & Neural Accelerator 3.5

- Intel® vPro® Enterprise

- Intel® AMT, ISM, RPE, One-Click Recovery

- Intel® Secure Key, Boot Guard, OS Guard, Control-Flow Enforcement

- Intel® Total Memory Encryption – Multi Key

- Virtualization: VT-x, VT-d, VT-rp, EPT

- Instruction Set: 64-bit, Extensions: SSE4.1, SSE4.2, AVX2

Package:

- Size: 45mm x 37.5mm

- Thermal Solution Spec: PCG 2020A

- Max Operating Temp: 105°C

3 YEARS WARRANTY
