ASUS MOTHERBOARD MATX PRIME H510M-K R2.0 DDR4 LGA1200 /INTEL 3Y

SPESIFIKASI

Brand: ASUS

Model: Motherboard MATX PRIME H510M-K R2.0

Color: Black

Chipset: Intel H470

CPU Support:

Intel® Core™ 11th Gen Processors

Intel® Core™ 10th Gen Processors

Intel® Pentium® Gold Processors

Intel® Celeron® Processors

Socket LGA 1200

Supports Intel® Turbo Boost Technology 2.0

Supports Intel® Turbo Boost Max Technology 3.0

Memory:

2 x DDR4 DIMM slots

Maximum Capacity 64 GB

Memory Speed 3200 OC / 3000 OC / 2933 / 2800 / 2666 / 2400 / 2133

Supports Dual Channel Memory Architecture

Supports non ECC Un-buffered Memory

Supports Intel® Extreme Memory Profile XMP

Graphics Output:

1 x VGA port

1 x HDMI port supports up to 4K

Expansion Slots:

1 x PCIe 4.0 / 3.0 x16 slot

1 x PCIe 3.0 x1 slot

Storage:

1 x M.2 slot supports PCIe 3.0 x4 and SATA

4 x SATA 6Gb per second ports

Audio:

Realtek 7.1 Channel High Definition Audio

USB Ports:

Rear USB:

4 x USB 3.2 Gen 1 Type-A

2 x USB 2.0

Front USB:

2 x USB 3.2 Gen 1

4 x USB 2.0

LAN: Realtek 1Gb Ethernet

Wireless Connectivity:

Not Available

Back Panel I O Ports:

4 x USB 3.2 Gen 1 Type-A

2 x USB 2.0

VGA

HDMI

1Gb LAN

3 x Audio Jacks

PS 2 Keyboard Mouse

Internal Connectors:

24-pin ATX Power Connector

8-pin 12V Power Connector

CPU Fan Header

Chassis Fan Header

M.2 Slot

4 x SATA 6Gb ports

USB 3.2 Gen 1 Header

2 x USB 2.0 Headers

RGB Header

Clear CMOS Header

COM Port Header

Front Panel Audio Header

S PDIF Out Header

Speaker Header

TPM Header

System Panel Header

Special Features:

ASUS 5X Protection III

DIGI Plus VRM

LANGuard

Overvoltage Protection

SafeSlot Core

Stainless Steel Back I O

Q DIMM

Q LED Core

Q Slot

Aluminum Heatsink Design

RGB Header

Operating System Support:

Windows 10 64-bit
